Handbook for machine designers, shop men and draftsmen (1916)
Halsey, Frederick A. (Frederick Arthur), 1856-1935 · New York, McGraw-Hill book company, inc.; [etc., etc.] · leaf 428
Fig. 13.-—Butt and double strap joint with straps atequal width. … Fig. 14.—Butt and double strap joint of the saw toothtype. rivets in the third row, two riv ets in the second row andone rivet in the outer iow = {P — 8d)tXT.S.-\-nXdXbXc.7 = crushing strength of plate in front of 16 rivets, plus thecrushing strength of butt strap in front of seven rivets=…
Machine design
