Handbook for machine designers, shop men and draftsmen (1916)
Halsey, Frederick A. (Frederick Arthur), 1856-1935 · New York, McGraw-Hill book company, inc.; [etc., etc.] · leaf 44
Fig. 21. Fig. 22. Fig. 23. Figs. 21 to 23.—End motion of a rotating journal. … Fig. 24.—Revolving element of the Glocker-White turbine governor. ing, the resultant R must be / P, since the resistance to sliding isthe same in aU directions. It at once follows that the applicationof the force F, however small, changes the direction of sliding fromthe direction of X to the…
Machine design
