ionary at its upper end, sleeve, c,revolving upon it. The result is absolute freedom of sleeve, c, torespond to the forces exerted by the fly balls. Bearings in which end motion takes place are free from the ten-dency to streak, which characterizes bearings with closely fitted endflanges. Thrust… … Fig. 25.—Multiple washer thrust bearing. that can be expected of such bearings is oily surface lubrication.The discovery of the film-forming tendency of journal bearings byBeauchamp Tower explained the weU-known fact that thrust bear-ings must be subjected to smaller unit pressures than journal…
