he form of finding a line in a givendirection passing through the center of gravity of a given section.Let the direction be OY. Draw a line OF in this direction and touch-ing the base of the figure. If the figure is curved at the bottom theline OY must be a tangent at the lowest point of the… … Fig. 5.—The center of gravity of irregular figures.X
