An illustration from Handbook for the use of electricians in the operation and care of electrical machinery and apparatus of the U. S. seacoast defenses .., 1904, leaf 36 — eads are etpial to each other and to the amount given by tlie l)uilder. tlie valveis properly .set. If not. change the valve rods length by the half difference, andre])eat the oi)eration, which will ])robably first reriuire a change of the eccentricsposition to bring the lead right at the first… … tan—u3—o THE STEAM ENGINE. 27 valve rods length is then changed by v? inch. Now i)ut crank at first deadcenter and change eccentrics position to give -f,.-inch lead and move crank(always in its working direction) to second dead center, and so on. (b) If the valve is controlled hy a wheel governor,…
