Handbook for the use of electricians in the operation and care of electrical machinery and apparatus of the U.S. seacoast defenses (1902)

United States. War Dept, Anderson, George Lucius, 1849-1934 · Washington, Govt. Print. Off. · leaf 85

An illustration from Handbook for the use of electricians in the operation and care of electrical machinery and apparatus of the U.S. seacoast defenses, 1902, leaf 85 — r conditions imposed in par. (A) 2, forisolated D. C. plants with battery reserves. But the apparatus is extensive andcurrent is lost in dead resistance while charging and lighting at the same time. 3. Details of the apparatus: (a) In the Weston voltmeter V, (fig. 79) a pivoted coil, of which only… … 1^ I^Lgl + 79. Present Generator Panel Apparatus in Detail. THE SWITCHBOARD. 59

Electric machinery · Searchlights · Coast defenses

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
