uring Points are the points by which any distancemay be measured on a receding line as it retires into thepicture, and may be found as follows :—Measure from theVanishing Point to the-Station Point ivitli the compasses, and-then set off on the Horizontal Line from theVanishiiig Pointtowards the… … IdIAI On Technical Perspectlm. 259 Diagram 13. To represent a cube in Angular Perspective. This may be done in two ways. First, draw tlieground plan, A B c D, at the desired angle, and (in thiscase) touching the G. L. Extend d b and d c respectivelyto the G. L. and observe the angles they make with…
