A hand book of general instruction for mechanics, containing useful rules and memoranda for practical men (1907)
Smith, Franklin Elijah, 1872- · New York, D. Van Nostrand company · leaf 316
Fig. 109 … Fig. 110 If a beam is resting on two supports and a weight isplaced on the beam between the supports, it is called atransverse stress. (Fig. 111.) 304 A HAND BOOK FOR MECHANICS If the beam be fixed at one end and loaded at the other,the stress is a bending stress. (Fig. 112.)
Mechanics · Arithmetic · Measurement
