Figs. 242 and 243.—Square and hexagonal order of bedding. The term bedding is an ex-pression used to indicate the relation between the cross sectional area of the winding whenwound square, as in fig. 242, and where wound in some other way, as in fig. 243. In thesquare order of bedding, the degree… … Fig. 244.—Method of securing coils in position when the pole pieces are simply extensions ofthe core without enlargement. Ques. How are the coils attached? Ans. Where the pole pieces are simply extensions of thecores without enlargement, the coils can be slipped over theends, but some kind of…
