Hawkins electrical guide. Questions, answers & illustrations; a progressive course of study for engineers, electricians, students and those desiring to acquire a working knowledge of electricity and its applications; a practical treatise (1914)
Hawkins, N. (Nehemiah), 1833- · New York, T. Audel · leaf 231
ly distributed. CONSTRUCTION OF ALTERNATORS 1,219 A partially distributed winding, then, is one, as in fig. 1,499,in which the coil slots do not occupy all the circumference of thearmature; that is, the core teeth are not continuous. A fully distributed winding is one in which the entire surfaceof… … PARTIALLY DISTRIBUTED WINDING FULLY DISTRIBUTED WINDING Fig. 1,499.—Partially distributed winding. Each coil unit is here divided into two concentriccoils of different dimensions and connected in series, as shown in detail in fig. 1.497. Thisbeing a whole coil winding the several units are so…
Electrical engineering
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
