ELECTRICITY Tlie principles of polypJiase motors can be best understood bymeans of elementary diagrams illustrating the action of poly-phase currents in producing a rotating magnetic field, as ex-plained in the paragraphs following. Production of a Rotating Magnetic Field by Two PhaseCurrents.—Fig.… … TWO-PHASE ALTERNATOR Fig. 1,659.—Production of a rotating magnetic field by two phase currents. The figure represents an iron ring, wound with coils of insulated wire, and supplied with two phase c_at the four points A, B. C. and D. The action of the two phase current on the ring inproducing a…
