Hawkins electrical guide. Questions, answers & illustrations; a progressive course of study for engineers, electricians, students and those desiring to acquire a working knowledge of electricity and its applications; a practical treatise (1914)
Hawkins, N. (Nehemiah), 1833- · New York, T. Audel · leaf 87
ondenser placed inseries with the single phase winding, as shown in diagramfig. 1.830r the two windings being displaced from each other ALTERNATING CURRENT MOTORS 1,345 on the armature about 90 magnetic degrees, just as in theordinary two phase motor. Ques. What is the construction of the two… … Figs. 1,859 to 1,^62.—Detail construction of clutch parts of General Electric drawn shell typefractional horse power single phase motor. The starting switch, which is assembled withinthe motor frame, consists essentially of three parts: a rotating member mounted on th ■armature and provided with…
Electrical engineering
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
