Hawkins electrical guide. Questions, answers & illustrations; a progressive course of study for engineers, electricians, students and those desiring to acquire a working knowledge of electricity and its applications; a practical treatise (1914)
Hawkins, N. (Nehemiah), 1833- · New York, T. Audel · leaf 146
to the commonwi-e of both phases at 3 Band D being connected asaforesaid, thus forming acommon connection forboth no voltage coils. Ter-minals aa and bb of theresistances must be con-nected to the outside mainacross the two phases, ter-minal 3 to the main com-mon to both phases, theconnections… … SCHEME OF 2 PHASE 3 WIRE NO VOLTAGE CONNECTIONS TO RESPECTIVE MAINS ON GENERATOR SIDE OF APPARATUS
