taneous operation; also circular retardation coils areused. Fig. 3,098 shows a simple diagram of the circuits. In practicethere are two circuits used called the physical and the phantom; theformer being the circuit proper and the latter an arrangement by whichthree circuits may be obtained from two… … Fig. 3,099.—Diagram of elementary fire alarm circuit. Fire alarm apparatus forms that ele-ment of the system depended upon to announce to the fire righting force the existence ofand location of a fire. The equipment consists of gongs and indicators located in the firedepartment houses, and where…
