Hawkins electrical guide ... : questions, answers & illustrations : a progressive course of study for engineers, electricians, students and those desiring to acquire a working knowledge of electricity and its applications ; a practical treatise (1914)
Hawkins, N. (Nehemiah), 1833-1928 · New York : T. Audel & Co. · leaf 115
ated from each other by aboutM<i of an inch, the space between the points being known asan air gap. This space offers so much resistance to the flow ofan electric current that a very high pressure is required to causethe current to burst through the air gap and produce a spark,hence the term… … ENGINE. CYLINDERS Fig. 3,980.—Wiring diagram for K-W typeH and HT magneto, for firing order1, 2, 4, 3. To time magneto: PlaceNo. 1 piston on upper dead center ofcompression stroke, and have rockerarm A, horizontal as shown. Shiftmagneto around until distributer brushB, touches segment S, thus…
