Hawkins electrical guide ... : questions, answers & illustrations : a progressive course of study for engineers, electricians, students and those desiring to acquire a working knowledge of electricity and its applications ; a practical treatise (1914)
Hawkins, N. (Nehemiah), 1833-1928 · New York : T. Audel & Co. · leaf 238
Figs. 4,158 and 4,159.—Cutler-Hammer direct current brake solenoids. Fig 4,158, short pull;fig. 4,159, long pull. Types of winding. In the case of the shunt wound solenoid, thereis a single coil connected directly across the line to release the brake. The compoundwound solenoid has a shunt and a…
Electrical engineering
