Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)
Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 148
FIG. 139.—SECTION THROUGH CYLINDERS AND VALVES. THE STURTEVANT COMPOUND ENGINE 137 … FIG. 140.— BACK PLATEN OF LOW-PRESSURE VALVE. The throw of the low-pressure eccentric should now be adjusted, theangular advance having been fixed when the keyway was cut in the eccentrichanger which is shown in Fig. 143.But before this can be done thedirection of rotation must be de-termined. As…
Steam-engines
