NEGATIVE CARBOM CONDENSER CONDENSERAXIS Fig. 3,859.—Motion picture arc for direct current. The advance displacement, say \i inch,causes the upper carbon to burn with a diagonal end containing the brilliant crater andthe light is accordingly thrown toward the condenser. That is to say, the positive…
