Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice (1921)

Ritchey, James, Monroe, Walter W. (Walter William), b. 1869 · Chicago, American technical society · leaf 166

An illustration from Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice, 1921, leaf 166
Fig. 263. Part of Arm Pattern forMiter Gear PATTERN MAKING 149 and at right angles to the edge a. Lay the edge b oi A againstanother board B, of the same thickness, and continue the line c onthis board, as shown by the dotted line. With the dividers seton the extended line c on the board B, and…

Patternmaking
