opposite side balances the crank-pin,and the part of the connecting-rod which revolveswith it. Two crank-disks may be used to take theplace of a double-armed crank. The following rules may be used in proportion-ing crank-disks: Di=D to 1.2D.B =.7D to D.A=.9B.C=.25D. F=2d. H=d to 1.5d.I^=B to 1.25B.…
