Henry and Hora's modern electricity; a practical working encyclopedia (1915)
Henry, James. [from old catalog], Hora, Karel Jan, 1881- [from old catalog] joint author · Chicago, Laird & Lee, inc. · leaf 177
wo diagrams of ring armatures, with thedifference that in the one on the right the coils are wound in opposite directions, and inthe other they are wound inft the same direction. Fig. 61 shows a diagram ofthe connections of an alterna-tor armature. The six coilsrepresent the coils of the ar-mature,… … Fig. 61. ELECTRICAL ENGINEERING 175 Coupling of alternators 137. Twc shunt-wound continuous current dynamos ofsimilar construction may be connected in parallel, and will
Electrical engineering
