center G F, whichis the run of the common rafter.Square up the rise G H anddraw F H for the length of thecommon rafter. The bevel at His the top bevel and at F thebottom bevel. G E being the runof the hip, square up the rise G1 and draw E I for length ofhip rafter. The bevel at I is thetop bevel… … Fig. 87.—Showing Howto Find ttie Lengthsand Bevels of JackRafters in an Octa-gon, Hexagon orPolygon. 126 THE BUILDERS GUIDE. and bevels of the jacks. Space the jacks on the lineC D and draw perpendicular to the hips, as shown,which will give the lengths. The bevel shown at L isthe bevel across the…
