stocks B and C. Now ourstrains are so distributed that when work is done at A thestrains will fall within the dotted triangle A, B, C, and the THE AMERICAN LATHE. 27 wider the base B, C of the triangle becomes in proportionto its height, the stronger the lathe will be, if the proper pro-portions of… … Fig. 1°. Comparative Strength of Wide and Narrow Triangles. b and c, Fig. 17, we then have our triangle of forces as A,b, c, in which the base b, c, is still wider; and this is cor-rect, because we take heavier cuts with the slide rest thanwe do when turning by hand, and consequently more forceis…
