Hicks' builders' guide : comprising an easy, practical system of estimating material and labor for carpenters, contractors and builders .. (1910)
Hicks, Isaac Perry, 1856- · New York : David Williams Company · leaf 33
ck. 600 + 32 == 632, thetotal area of the roof. This rule will apply to hip roofs of most any kind.If the roof is pyramidal in form and hips to a point,as shown by Fig. 24, then there is nothing to add fordeck, and we simply multiply one-half the length atthe eaves by the length of the common… … Fig. 26.—Plan of Roof with Four Gables. gable hipped on the rear side, as shown in the diagram.Fig. 27 shows this roof as it would appear in the frontside elevation. Referring now to Fig. 28, A B and
Carpentry · Building
