a 110-volt, 60-cycle alternating current, preferably from the local centralstation. Beside the main switch, the switch for the spark gapmotor should be located. The primary terminals of thetransformer are to be connected with the main switch, asshown in the wiring diagram below, which also shows… … HIGH FREQUENCY PLANT CULTURE 201 From one terminal of the spark gap a piece of strandedcable, composed of 100 strands of about Xo. 24 insulatedmagnet wire, runs to one terminal of the condenser. Fromthe other terminal of the condenser, a piece of the strandedcable leads to the movable clip on the…
