Hints to young architects, comprising advice to those who, while yet at school, are destined to the profession, to such as, having passed their pupilage, are about to travel and to those who, having completed their education, are about to practise, together with a model specification involving a great variety of instructive and suggestive matter (1887)

Wightwick, George · London, Lockwood · leaf 145

An illustration from Hints to young architects, comprising advice to those who, while yet at school, are destined to the profession, to such as, having passed their pupilage, are about to travel and to those who, having completed their education, are about to practise, together with a model specification involving a great variety of instructive and suggestive matter, 1887, leaf 145
ostatic arch is identical with an 132 HINTS TO YOUNG ARCHITECTS. elastic curve, as tliat of an umform spring when bent, andits application to the intrados of an arch-ring is useful.*Strains found graphically.—As an example of thegraphic method of finding the strains on trusses wegive the following… … Fig. 40.

Architecture

Internet Archive · University of Toronto, Robarts Library · Public Domain Mark 1.0. Free to use for anything.
