Hints to young architects, comprising advice to those who, while yet at school, are destined to the profession, to such as, having passed their pupilage, are about to travel and to those who, having completed their education, are about to practise, together with a model specification involving a great variety of instructive and suggestive matter (1887)
Wightwick, George · London, Lockwood · leaf 145
Fig. 40. … Fig. 41. reactions of walls (shown out of the perpendicular,to avoid overlapping of the lines). To draw the dia-gram of stresses (fig. 41), the polygon of externalforces is first drawn by making f^, F2, . • • ^2? ^iGj, G2 . . . parallel to the corresponding lines in the * For a full investigation…
Architecture
Internet Archive · University of Toronto, Robarts Library · Public Domain Mark 1.0. Free to use for anything.
