Hints to young architects, comprising advice to those who, while yet at school, are destined to the profession, to such as, having passed their pupilage, are about to travel and to those who, having completed their education, are about to practise, together with a model specification involving a great variety of instructive and suggestive matter (1887)

Wightwick, George · London, Lockwood · leaf 236

An illustration from Hints to young architects, comprising advice to those who, while yet at school, are destined to the profession, to such as, having passed their pupilage, are about to travel and to those who, having completed their education, are about to practise, together with a model specification involving a great variety of instructive and suggestive matter, 1887, leaf 236
se- brickorrub- tional form and size ble. here shown and figured.The same to be coveredwith a semicircular 4brick arch, having aman-hole, with stonetherein, 20 diameter,and iron ring. The sidesto be of (rubble, orbrick-work), the bottom,of (ditto), and formingan inverted segment.The ground outside… … No. 48. Leave proper and sufficient openings for venti- Ventilation. lating under the joists of ground floor, and pro-vide and fix neat gratings [of cast iron or glazedearthenware] in said openings. Form air flues,where shown, in thickness of walls.(See Sanitary Construction, Part V.) No. 49.…

Architecture

Internet Archive · University of Toronto, Robarts Library · Public Domain Mark 1.0. Free to use for anything.
