Hints to young architects, comprising advice to those who, while yet at school, are destined to the profession, to such as, having passed their pupilage, are about to travel and to those who, having completed their education, are about to practise, together with a model specification involving a great variety of instructive and suggestive matter (1887)

Wightwick, George · London, Lockwood · leaf 32

An illustration from Hints to young architects, comprising advice to those who, while yet at school, are destined to the profession, to such as, having passed their pupilage, are about to travel and to those who, having completed their education, are about to practise, together with a model specification involving a great variety of instructive and suggestive matter, 1887, leaf 32
Fig. 12. TAKE OF THE FORM OF THE SURFACE UPON WHICH THEY ARE THROWN.—Flat surfaccs rcccive the form CAST SHADOWS. 19 \\ … Fig. 13. of tlie object, modified only according to the angle whichthe rays of light make with the plane. Thus, whenthe plane is perpendicular to therays of light, and the object in-terposed also perpendicular orparallel to the plane, the shadowresembles the shape of the object,and when cast by the…

Architecture

Internet Archive · University of Toronto, Robarts Library · Public Domain Mark 1.0. Free to use for anything.
