Ferris, Richard. [from old catalog] · New York, T. Nelson and sons · leaf 208
Sectional diagram of the 5-cylinder R-E-P motor; of the radiant type. … Sectionaldiagram of the 5-cylinder Bayard-Clement motor; of the star type. 208 FLYING MACHINES: MOTORS. offset of the crank-shaft of half the stroke of the pis-tons, whose rods are all connected with the crank-shaft. The entire system revolves around the mainshaft as a centre, the crank-shaft being…
Aeronautics
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
