How to study architecture; by Charles H. Caffin ... an attempt to trace the evolution of architecture as the product and expression of successive phases of civilisation (1917)
Caffin, Charles Henry, 1854-1918 · New York, Dodd, Mead and Company · leaf 253
SECTION OF SS. SERGIUS AND BACCHUS,CONSTANTINOPLE Showing Fluted or Melon-Shaped Dome,Supported on Eight Arches and Squinches.Note Lights Round Dome. P. 206 DIAGRAM Showing How the PExN-DENTivES, Resting onFour Angles of aSquare, Provide a Cir-cular Base for theDome. P. 205 … SECTION OF S. SOPHIA, CONSTANTINOPLE Showing Pendentive Dome. P. 207. Small Diagram, at Right, ShowsHow a Dome Was Made to Rest on Eight Piers Enclosing an Octagon, byNiches or Squinches.
Architecture
Internet Archive · Wellesley College Library · Public Domain Mark 1.0. Free to use for anything.
