onry tunnel;and finally, for 3,936 feet, it is again a steel pipe, 2.62 feet in diameter.At the end of the last section, the pipe branches into three pipes,each of 1.64 feet diameter. One of these pipes extends to the j)o\\ci-plant; but the others are plugged, and will be built to the power-house… … head of water is only 089 feet; but from this point on, the desctni isverv abrupt. At this point, also, there is a retaining valve, and avertical stand pipe (regulator) 1.31 feet in diameter, and 82 feet high,which relieves the water-hammer in the pipe-line above. 215. The steep-grade pipe-line,…
