Hydraulic motors, with related subjects, including centrifugal pumps, pipes, and open channels, designed as a text-book for engineering schools (1905)
Church, Irving Porter, 1851-1931 · New York : J. Wiley & Sons; [etc, ] · leaf 114
Fig. 43. Fig. 44. We next find in Combes turbine (Fig. 44) man} jets, occupy-ing the entire circumference, guided between vanes, or blades,fixed in a ring attached to a shaft, the water being suppliedfrom underneath through a fixed pipe or tube. No interiorfixed guides were provided to direct the…
Hydraulic machinery
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
