Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 278

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 278
1096. CLOVER-LEAF CAM, for rectili-near motion by follov^er rollers on a bar.The cam is so designed that the rollers havea bearing in all its positions. … 1097. POWER ESCAPE-MENT for heavy machines. Thetraverse bar may be vibrated bythe positive motion of the camarms.

Mechanical movements
