The illustrated architectural, engineering, & mechanical drawing-book : for the use of schools, students, and artisans ; upwards of 300 illustrations (1856)
Burn, Robert Scott · London : Ward and Lock, 158 Fleet Street · leaf 136
lig. 47. EXGIXEERIXG, AND MECHANICAL DRAWING-BOOK. Example io, tig. 48. 133 … fig. -18. We now proceed, as a conclusion to this department, to give a fewexamples to serve as copies to the student, in copying which he will findhis operations much facilitated if he has paid full attention to the pre-liminary lessons. The copies given in perspective are set out by the rulegiven…
Architectural drawing · Mechanical drawing
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
