An illustration from Illustrated and descriptive catalog of Whitin cotton combing machinery : and handbook of useful information for overseers and operatives, 1922, leaf 65 — hten these cams. Setting Brass-Clearing Rolls. These rolls should be setparallel with the steel-detaching roll and quite clear from the leather-detaching rolls. Set the brass rolls the thickness of No. 18 gaugefrom the leather rolls. Recapitulation of Timing of Parts of Combing Machine.Nippers… … w^^l0^..^l Page 62 CALCULATIONSfor Model D-2 Comber To find the total draught: Let L = lap roll change gear, and C = the coller connectiongear, then the total draught between the lap rolls and the deliveryrolls of the coiler is obtained as follows with reference to gearingdiagram of D-2 Comber. 47…
