An improved and enlarged edition of Biddle's young carpenter's assistant : being a complete system of architecture for carpenters, joiners, and workmen in general, adapted to the style of building in the United States ; revised and corrected, with several additional articles, and forty-eight new designs, chiefly of full size, working drawings of modern finish, in detail ; particularly adapted for country use (1833)
Biddle, Owen, Haviland, John, 1792-1852 · Philadelphia : M'Carty & Davis, 171 Market Street · leaf 111
THE YOUNG CARPENTERS ASSISTANT. 31 of these is shown in the section A hy d d d. Fig. C is one of the ribs or rafterswith a mortise in the middle of it long enough to receive two of fig. D, and ateach end a sliding mortise of half that length, represented in section A hy c c c.When these are to be…
Architecture · Architectural drawing
