An improved and enlarged edition of Biddle's young carpenter's assistant : being a complete system of architecture for carpenters, joiners, and workmen in general, adapted to the style of building in the United States ; revised and corrected, with several additional articles, and forty-eight new designs, chiefly of full size, working drawings of modern finish, in detail ; particularly adapted for country use (1833)

Biddle, Owen, Haviland, John, 1792-1852 · Philadelphia : M'Carty & Davis, 171 Market Street · leaf 127

An illustration from An improved and enlarged edition of Biddle's young carpenter's assistant : being a complete system of architecture for carpenters, joiners, and workmen in general, adapted to the style of building in the United States ; revised and corrected, with several additional articles, and forty-eight new designs, chiefly of full size, working drawings of modern finish, in detail ; particularly adapted for country use, 1833, leaf 127
PLATE 45 … THE YOUNG CARPENTERS ASSISTANT. 35 pitch-board in A up till it strikes the riser of the second step, as from 8 to 7, and setthat space off at C from 8 to 7; at Avhich place square over a strong mark, the useof which will be explained hereafter. To draw the Falling-mould. Draw the pitch-board at D;…

Architecture · Architectural drawing

Internet Archive · Public Domain Mark 1.0. Free to use for anything.
