Industrial drawing and geometry; an introduction to various branches of technical drawing (1911)
Spooner, Henry John, 1856- · London, New York [etc.] Longmans, Green, and co. · leaf 133
Fig. 344.—Elevation of stuffing box gland. Pigs. 340, 341.—Hook bolt( Amer. Proj.), plan overelevation. Pig. 342.—End elevation. … -Auxiliary plan to shov^ method ofdrawing. looking in the direction of the arrow M. 200. To draw a Stuflftng Box Gland.Scale full size.—Figs. 345 and 344 show, inplan and elevation, a gun-metal stuflBng boxgland (fully dimensioned) for a 2^ pistonrod or valve spindle/ used to hold thepacking in the…
Mechanical drawing · Geometrical drawing
