Information; elementary electricity, motor car electric systems, the gas engine from an ignition point of view, driving the car (1920)
Phillips, Harvey Elmer, 1874-1948 · Dayton, Ohio, Auto Electric Systems Publishing Company · leaf 216
arbon filament bulbs, or generator not charging properly. If the ammeter registers discharge with all lights and the ignition off and the engineidle, it would indicate that there is current from the battery being dissipated in a short circuitin the wiring or that the ammeter is out of order. To… … Fig. 33. 214 INFORMATION If the ammeter does not register charge with all lights off and the engine running, itwould indicate that the generator was not charging properly. An inspection should be madeof both relay and regulator contact points and all dust and dirt carefully removed. A smallquantity…
Automobiles
Internet Archive · Boston College Libraries · Public Domain Mark 1.0. Free to use for anything.
