FIG. 5 Figure 5 shows a number of symbols which are used in the various illustra-tions. A. shows a motor or generator brush. B a field coil. C a motor or generatorcommutator. D shows resistance wire. E shows a cut-out relay. F is a pushbutton. G is an ammeter. H is a voltmeter. I and J are…
