O o FIG. 25 Figure 25. This shows an ammeter connected across the primary terminalsof the cut-out relay. If, when the generator is running and it does not close atthe proper time, test as shown. If generator is generating, the ammeter will showa reading. This indicates an open circuit in the… … o o x <0 r H CD>H m < FIG. 26 Figure 26. This shows test for open shunt field. Be sure to disconnect allwires from the generator. Then use test cord from 110-volt circuit, with lampcut in on one side of the line as shown. If the lamp burns at all or there is aspark when the two points are…
