Information; elementary electricity, motor car electric systems, the gas engine from an ignition point of view, driving the car (1920)
Phillips, Harvey Elmer, 1874-1948 · Dayton, Ohio, Auto Electric Systems Publishing Company · leaf 304
10 testcords and special picture instruction book are supplied with each set. No servicestation or garage is complete without this instrument. No danger of injuring theinstruments if wrong connections are made in testing automobile electric systems.If the user allows the ammeter to remain in a… … Figure 58. Method of increasing or decreasing the output of a generator em-ploying third brush regulation. Dotted line represents the field coil circuit. Toincrease the output of the generator, move brush A toward brush B. To de-crease output of the generator, move brush A toward brush C. Figure…
Automobiles
Internet Archive · Boston College Libraries · Public Domain Mark 1.0. Free to use for anything.
