an impres-sion of same on the wnx. Cut out that portion of the waxthe surface of which, according to the map, would be belowthe contour just traced. Take the remainder of the sheet 34 jNIilitary Sketching and Map Reading of wax and place it uj)on the base established in the othersquare. Refill the… … Fig. 7 Next, slope off abrupt surfaces between the heavy con-tours by moulding in small pieces of wax by hand, and themap is then completed in so far as the relief is concerned. Next, all of the natural and artificial features of theterrain are represented by indentations in the wax. Thisis easily…
