es of wax by hand, and themap is then completed in so far as the relief is concerned. Next, all of the natural and artificial features of theterrain are represented by indentations in the wax. Thisis easily done by whittling out small, soft pine sticks to Reijef Maps 35 represent the various… … Fig. 8 in, or, better, stamped in with rubber stamps or steel type.Every feature is easily represented, and quickly indentedon the surface of the wax. When you have no further usefor a particular relief map, it may be torn up and another 86 Military Sketching and Map Reading one constructed from…
