Military sketching and map reading; including panoramic sketching and aerial photography (1921)
Grieves, Loren Chester, 1878- · Washington : United States Infantry Association · leaf 55
te by adash. If several coordinates are given, as would be neces-sary in locating a certain line on the map, the coordinateslocating each point of the line are sei)arated by commas. Suppose we wish to locate the R. Schwartz house. (SeeIVIap.) We find that it is 354.4 thousand yards east ofthe… … Fig. 16 Coordinates 53 746.8 as the coordinates of the house which locates itdefinitely. XoAV suppose that we wish to locate the line: R.Schwartz house—point 473- point 536, the coordinateswould be as follows: 354.4-746.8, 354.7-747.6, 355.6-748.6,separating each set of coordinates by a comma.…
Maps, Military · Military sketching
