g description will help to elucidatethem. In the first place it will be noticed that the engine isessentially a marine one, the bearing arms being cast on 240 THE INTERNAL COMBUSTION ENGINE the bottom half of the bed-plate, and large doors beingfitted in the upper half to enable adjustments to be… … Fig. 72. General Arrangement of Thornycroft 6 XParaffin Engine—End view. Marine Petrol or N surrounding them ; these water-jackets extend sufficientlyfar down to enable the working parts of the cylinders to becompletely covered. 0 is the piston fitted with five pistonrings ; P the connecting rod…
