y 22, 1907. 286 THE INTERNAL COMBUSTION ENGINE therefore short circuited as long as lever 7 is in contact with platinumscrew 5. The circuit is interrupted when the lever is rocked. Acondenser 8 is connected in parallel with the gap thus formed. Secondary Winding.—The beginning of the secondary… … Fig. 107.—Arrangement of Bosch H.T. Magneto. insulated from the magneto frame by means of the carbon holder 11.From the brush 10 the secondary current is conducted to the con-necting bridge 12, fitted with a central carbon brush 13, and throughthe rotating distributor piece 14, which carries a…
