The internal combustion engine; a text-book for the use of students and engineers (1915)
Wimperis, Harry Egerton, 1876- · New York, D. Van Nostrand company · leaf 257
Fig. 65.—Enlarged view of Exhaust valve ofEngine shown in Figs. 63 and 64. 234 THE INTERNAL COMBUSTION ENGINE [chap, vni … of oil is controlled by the governor in the following way.The oil passes through a valve-box with two valves, one ofwhich leads to the vaporizer and the other leads to an overflow Chap, viii] OIL AND PETROL ENGINES 235 from which the oil can flow back to the tank. If the speed rises beyond the…
