Bradbury, F. (Fred) · Manchester : John Heywood Ltd. · leaf 24
ABCDFig. 9. In all the illustrations from Figs. 1 to 30, the following indica-tions are common.l — The lease rods.H1 etc. = the heddles. x = The order of drafting the warp threads through the heddles.t = The order of lifting the heddles, denominated tramp, pegging plan or shedding. 20 JACgUARD…
Textile machinery
